ZTAMW06-1

Configuration parameters of self-propelled steering cylinder single column 6m aluminum alloy
Model gtwy06-1
Maximum working height 8M
Maximum platform height 6M
Safe working load 150kg
Working platform size (length) × wide × Height) 945 * 700 * 1160
Overall dimension (length) × wide × High)
A × B × C
1646*770*2096
Maximum workers1
Minimum ground clearance 0.5m
Wheelba<x>se 1.34m
Lifting motor 24V / 2.2kw
Lifting speed 3-5M / min
Tire front wheel 305 * 100 rear wheel 305 * 100
Table material Q235
Table guardrail 30mm * 30MM square tube
One oil cylinder Hebei Hengyu with a diameter of 40mm
Ningbo Tiandi hydraulic pump station
Strut material: 5 masts aluminum alloy thickness: 6.5
Electric handle control
Q235 steel plate rectangular pipe of underfr<x>ame

PRODUCT DETAIL

Model	ZTAMW06-1
Maximum working height	8M
Maximum platform height	6M
Safe working load	150KG
Working platform size (length) × wide × Height)	945 * 700 * 1160MM
Overall dimension (length) × wide × High) A × B × C	16467702096MM
Maximum workers	1
Minimum ground clearance	0.5M
Wheelbase	1.34m
Lifting motor	24V / 2.2kw
Lifting speed	3-5M / min
Tire	front wheel 305 * 100 rear wheel 305 * 100
Table material	Q235
Table guardrail	30mm * 30MM square tube
Oil Cylinder	Hebei Hengyu, with a diameter of 40mm
pump station	Ningbo Tiandi hydraulic
Strut material	5 masts, aluminum alloy thickness: 6.5mm
Electric	handle control
Underframe	Q235 steel plate rectangular pipe
