ZTCP-3 CARS

1. The standard depth of the pit is 4.45m and the load of each floor is 2.3t.
2. The parking height of the negative first / second floor is 1.8m the underground entry width is 2.1m and the vehicle is over long and protected against falling;
3. Overall dimension of equipment: 5400 * 2900 * 4450;
4. The vehicles on the negative first / second floor are warm in winter and cool in summer anti-theft rain and snow proof and the vehicles on the first / second floor can enter and leave freely which is intelligent and practical;
5. Comply with CE standard voltage system key operating system voltage: 380V and the foundation shall be constructed according to the manufacturer's requirements;
6. The motor power is 5.5kW and the reducer sprocket is lifted;
7. The rising time is about 50s and the falling time is about 35S;
8. Process: shot blasting spraying / non painting treatment;
9. Space height requirements: ≥ 5.6m;
Its cost is usd8980

PRODUCT DETAIL

1. The standard depth of the pit is 4.45m, and the load of each floor is 2.3t.

2. The parking height of the negative first / second floor is 1.8m, the underground entry width is 2.1m, and the vehicle is over long and protected against falling;

3. Overall dimension of equipment: 5400 * 2900 * 4450;

4. The vehicles on the negative first / second floor are warm in winter and cool in summer, anti-theft, rain and snow proof, and the vehicles on the first / second floor can enter and leave freely, which is intelligent and practical;

5. Comply with CE standard voltage system, key operating system, voltage: 380V, and the foundation shall be constructed according to the manufacturer's requirements;

6. The motor power is 5.5kW, and the reducer sprocket is lifted;

7. The rising time is about 50s and the falling time is about 35S;

8. Process: shot blasting spraying / non painting treatment;

9. Space height requirements: ≥ 5.6m;
