ZTVL versatility accessibility lifting platform is the use of steel frame precision screw driver or driven hydraulic power unit system a versatile type of vertical lifting platform. Products can enhance the range according to customer needs safety performance installation design without pit to bring you the construction of the border barrier-free access and an elevator like to enjoy widely used in residential areas hotels administrative offices buildings subways banks stadiums hospitals and other public places;

PRODUCT DETAIL

Stair elevator home used disabled wheelchair lifting equipment for sale

Features:

1.Platform size: 1200mm(L)* 1000mm(W)

2.Min Platform height: 60mm

3.Load capacity: 250KG~350KG

4.Vertical hydraulic lift platform

5.it could be customised,please tell us your detail requirement,our egineer will design according it.

Technical parameter:



Platform size

1200mm(L)* 1000mm(W)

Dimension

1200mm(L)*1450mm(W)* Travel height +600-700 mm(H)

Max Platform Height

mm

Min Platform height

60mm

Configuration

Open through or front and side entrances

Speed

60mm/s

Load capacity

250KG~350KG

Control voltage

24V/DC

Power Output

2.2KW

Power Input

220V/50HZ/25A (or customized for local power supply)

Drive System

Hydraulic  or screw

Control Mode

Inching Switch or Automatic

Drive Control

Self-resetting system

Overload

Protection Over current relay

Material of Platform

Plastic electrostatic spraying

Painting

Plastic electrostatic spraying

Guard panel & drive cabinet

(framework)

Aluminum Alloy / 304 stainless steel



Operation Panel

Polished aluminum Alloy

Safety Wane Working Range

75°

Working Condition

Both indoors and outdoors

Working temperature

From -10°~60°C

Installation



Non-pit installation, directly fixed to concrete floor

(the concretefloor below the platform shall not be

lower than the ground)

Control Device



Calling box (installed on the wall nearby) and remote

controller(Extra optional)

Emergency Stop



The lifting and lowering process can be stopped immediately

by pressing the emergency button.

Safety device

Safety Interlock

Lock the platform when it is out of control

Safety Sensor

The operation must be stopped immediately

the safety edge meets obstacles during

operation.

Emergency lowering

The platform can be lowered by opening

hydraulic valve manually or rolling screw rod.

Auto-flap

Turn up after lifting
